714 SEMI AUTOMATIC RANDOM CASE SEALER

 The Endoline type 714 is a semi automatic random case taper that is capable of sealing random cases down to a height of just 110mm. This case sealer enables the operator to seal cases of different dimensions in any order with no manual adjustment. The machine can be used with a semi automatic case erector to offer a solution to erect, load and seal cases of random sizes.

CASE DIMENSIONS

The type 714 can handle cases between 185-990mm length, 140-460mm width and 110-520mm height.

TAPE SIZE

38mm, 50mm, 75mm

MACHINE FINISH

Mild steel, powder coated white (RAL9010) or stainless steel.

BESPOKE OPTIONS

Any of Endoline’s machines can be modified or customise designed to suit your specification, if you can’t find exactly what you want then contact Endoline and a Sales Engineer will discuss your requirements with you in full.

Key Factors

  • Random Case Sealing

    This machine will automatically adjust its settings to seal 0201 cases throughout the case size range in any random sequence. This machine can operate on small, large, lightweight or heavy cases and can be used with a semi automatic case erector to offer a random solution to erect, load and seal cases.

  • Compact Footprint

    With a surprisingly compact footprint these machines will fit in to areas with restricted floor space or areas not normally suited to the installation of large or bulky machinery.

  • Robust construction

    High quality components housed in a robust chassis ensure minimal servicing and enable 24 hour operation. These systems are designed for the rigours of typical end-of-line packaging environments.

  • Low Cost Of Ownership

    The Endoline case erector machine range is designed to give you the best possible value for your investment through maximum productivity with minimal stoppage time. All Endoline’s machines are built for 24/7 operation and require little maintenance offering a long life expectancy resulting in a low cost of ownership.

Watch the video

*The video shown is for illustrative purposes only and may differ according to order specification.
